Wam Make Butterfly Valves 100 MM / 150 MM /200 MM / 250 mm /300 MM

Name: Wam Make Butterfly Valves 100 MM / 150 MM /200 MM / 250 mm /300 MM
Brand: Khurana Tractors
Price: 4500.0 INR
Availability: InStock

Price 4500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Wam Make Butterfly Valves 100 MM / 150 MM /200 MM / 250 mm /300 MM Specification

Product Type
Butterfly Valve

General Use
Industrial, Pneumatic Conveying, Dust Filtration, Powder Handling Applications

Material
Aluminium Alloy Body, Stainless Steel Disc, EPDM/NBR Seal

Type
Wafer Type

Capacity
Suitable for air, dust, powders, and granules

Weight (kg)
Varies by model: 100mm (approx. 4.8 kg), 150mm (5.8 kg), 200mm (7.2 kg), 250mm (8.6 kg), 300mm (10.0 kg)

Computerized
No

Automatic
Optional (Manual/ Pneumatic Actuated Options)

Automatic Grade
Manual / Automatic

PLC Control
Optional with Actuator

Method
Quarter Turn Rotary Operation

Drive Type
Manual Lever or Pneumatic Actuator

Voltage
Not Applicable for Manual, Pneumatic Actuated: 24V/230V Solenoid Valve

Dimension (L*W*H)
Depends on valve size, for example: 100mm, 150mm, 200mm, 250mm, 300mm as per manufacturer specification

Feature
Compact structure, Maintenance free, Leak-proof, Lightweight construction, Quick installation

Disc Material
Stainless Steel

Seat Type
Replaceable

Body Finish
Epoxy Powder Coated

Handle Type
Notched Lever handle or Pneumatic Cylinder

Size Range
100 mm, 150 mm, 200 mm, 250 mm, 300 mm

Working Pressure
Up to 2 bar

Application Media
Air, Dust, Bulk Powder, Granules, Light Slurry

Seal Material
EPDM or NBR

End Connection
Wafer Compatible with PN10, PN16, ANSI150 Flanges

Standards
Conforms to international quality standards for industrial valves

Mounting Position
Any

Temperature Range
-10C to +80C (Depending on seal type)

Wam Make Butterfly Valves 100 MM / 150 MM /200 MM / 250 mm /300 MM Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
110 Pieces Per Month

Delivery Time
60 Months

About Wam Make Butterfly Valves 100 MM / 150 MM /200 MM / 250 mm /300 MM

Our importedButterfly Valves 250 mm Dia Double Flanged / Single Flanged:-

To close silos, hoppers or bins containing powders or granules, VFS Butterfly Valves range among the most widely used equipment worldwide.

What used to be custom-built items for specific applications, WAM has turned into a mass-produced, industrial product with features that allow extremely versatile use.
VFS Butterfly Valves are used in all types of powder and granular material processing plants where interception of gravity-fed or pneumatically conveyed dry materials is required. They are fitted beneath hoppers, bins, silos, screw or other type conveyors, or to intercept pneumatic conveying ducts. Due to their special design and engineering materials used, they represent a particularly cost-effective yet most efficient solution.

Versatile Size Range and Compatibility

These butterfly valves are offered in a comprehensive size range from 100 mm to 300 mm, ensuring suitability for varied industrial setups. Engineered for maximum compatibility, their wafer design fits seamlessly between PN10, PN16, and ANSI150 flanges, allowing for easy replacement, scaling, or integration into existing pipelines.

Durability and Leak-Proof Performance

Constructed with a robust aluminium alloy body and stainless steel disc, the valves offer exceptional resistance to corrosion and wear. Their replaceable EPDM or NBR seals provide reliable, leak-proof service across a wide temperature range, making them suited for challenging environments in pneumatic conveying and filtration systems.

Flexible Operation and Customization

Depending on process requirements, these valves can be operated manually with a notched lever handle or automatically with a pneumatic actuator. The automatic option allows for PLC control via a 24V/230V solenoid valve, supporting enhanced automation and process efficiency in complex industrial applications.

FAQ's of Wam Make Butterfly Valves 100 MM / 150 MM /200 MM / 250 mm /300 MM:

Q: How do I select the correct size of butterfly valve for my application?

A: To choose the right size, consider your pipeline diameter and required flow rate. The Wam Make Butterfly Valves are available in 100 mm, 150 mm, 200 mm, 250 mm, and 300 mm sizes, which should match your piping dimensions. Always ensure compatibility with your system's flange standards and check suitability for your specific media type.

Q: What are the maintenance requirements for these butterfly valves?

A: These valves are designed to be virtually maintenance-free thanks to their durable construction and replaceable seat seals. Routine visual inspections are recommended, especially in high-duty cycles or abrasive media applications, to ensure the valve continues to operate leak-free and without obstruction.

Q: Where can these valves be used within an industrial setting?

A: Wam Make Butterfly Valves are ideal for pneumatic conveying, dust filtration, and powder handling installations. Their robust design and compatibility with various flange standards allow use in air, dust, bulk powder, granule, and light slurry applications across multiple industrial sectors.

Q: What operational options are available for these valves?

A: You can operate these valves manually using a notched lever handle, or opt for pneumatic actuation for automated control. The pneumatic option enables integration with PLC systems via compatible solenoid valves, offering increased process automation and monitoring.

Q: How does the sealing material affect performance and temperature range?

A: The choice between EPDM and NBR seals depends on the media and temperature range required. EPDM is suitable for air, dust, and most powders with a broader temperature range, while NBR is preferable when dealing with light slurries or oils. Always select the seal material that matches your process conditions for optimal leak-proof performance.

Q: What benefits do these butterfly valves offer industrial users?

A: Key advantages include lightweight construction, compact design, ease of installation, leak-proof operation, minimal maintenance, and flexible mounting in any position. Their broad compatibility and customizable operation make them a cost-effective solution for a variety of industrial flow control challenges.
